MO 377
Fingertip Joystick
- Contactless Hall Effect measuring principle
- Redundant or Full Redundant
- +5 million Lifetime cycles for Spring Return
- +1 million Lifetime cycle for Detent
- +1 million Lifetime cycle for Rocker
- Lever Operating Angle:
- ± 30° max. for Rocker, Friction
- ±35° max. for Detent
- 60° max. for Back Turn
- Customized output signal program option, customized wire harness, customized color options
- Single axis Actuation
- No Detent, With Detent, Rocker, Friction, Back Turn, Friction with Middle Detent Actuation Type
- -40C° … +85C° Operating Temperature
- IP6K9K Electronic Ingress Protection
- IP54 Mechanical Ingress Protection
- 5V or 8-32V Supply Voltage
- Analog or PWM Output Option
- Ratiometric Analog Output, Programmable 0 – 5 V / PWM (100-500 Hz – 5V)
Color Options
1-RED
RAL 3001
2-GREEN
RAL 6010
3-YELLOW
RAL 1023
4-BLACK
RAL 9005
5-BLUE
RAL 5005
6-ORANGE
RAL 2010
7-GRAY
RAL 7043
Technical Drawing
Durable & Customizable Legends
Legends are engraved with laser for durability and resistance to scratch and abrasion, ensuring the first day appearance for the entire life cycle. Legends can also be customized upon customer requirements, laser engraving ensures a wide variety of legends to satisfy customer expectations.
Order Code
MO 377 - | HXX - Hardware Configuration | X - Detent | X - Color | XX - Symbol | PXXX - Program | XX Connection |
|---|---|---|---|---|---|---|
H10 - Full Redundant | 0 - No Detent | 1 - Red | 00 - No symbol | P001 - Dual Cross - No Detent | 00 - 250mm Loose Cable (AWG 24) | |
H16 - Redundant | 1 - Detent Hold | 2 - Green | XX - Symbol | P002 - Single - No Detent | 01 - Molex Micro-Fit Connector 250mm Cable | |
2 - Rocker | 3 - Yellow | *See symbol table for symbol codes | P003 - Dual Cross - Rocker | ** | ||
3 - Friction | 4 - Black | * | P004 - Single - Rocker | |||
4 - Back Turn | 5 - Blue | P005 - Dual Cross - Detent Hold | ||||
5 - Friction with Middle Detent | 6 - Orange | P006 - Single - Detent Hold | ||||
6 - Detent Return | 7 - Gray | P007 - Dual - Back Turn | ||||
7 - Back Turn with Detent | P008 - Single - Back Turn | |||||
8 - Detent Single Side | P009 - Dual - Friction | |||||
P010 - Single - Friction | ||||||
P011 - Dual - Friction with Middle Detent | ||||||
P012 - Single - Friction with Middle Detent | ||||||
P013 - Dual - Detent Return | ||||||
P014 - Single - Detent Return | ||||||
P015 - Dual - Back Turn with Detent | ||||||
P016 - Single - Back Turn with Detent | ||||||
P017 - Dual - Detent Single Side | ||||||
P018 - Single - Detent Single Side |
* No symbol is standard, other symbols are available upon request with minimum order quantity.
** 250mm loose cable is standard, Deutsch DTM seal connectors available with minimum order quantity
Example: MO 377 – H10 – 0 – 1 – 00 – P001 – 00
