MO 390 & 394
CAN Joystick
- Contactless Hall Effect Measuring Principle
- Full Redundant
- Up to 5 million lifetime cycle
- 2 Axis Full, 2 Axis Plus, Single Axis Actuation
- Deutsch 8 & Tyco 18 Pins connector
- Various grip customization with different types of thumbwheels and number of buttons on request
- ± 20° Lever operating angle
- Self Centering Lever
- IP67 Ingress Protection
- 5V or 8-32V Supply Voltage
- High current power output option
- Customized output signal program option
- CAN j1939 or CANopen output option
- -40C° ~ +85C° Operating Temperature
Order Code
Joystick Grip * | |
Joystick Base |
* For MO 390+394 full assembly option, MO 394 grip only available as Analog output.
