MO 382
Tractor Pedal
- Suspended type
- Suitable for different engine interfaces
- Contactless measuring principle
- Full redundant double programmable outputs
- Dual Analog type : 0-5V / PWM
- Analog+IVS type : Analog+Highside or Lowside Switch
- Analog, PWM, IVS options
- 5V or 8-32V Supply Voltage
- Virtual effect option
- IP6K9K Sensor
- 6 way, Delphi Packard Metric Pack 150
- Two independent springs
- -40°C … +85°C Operating Temperature
- More than 2 million actuation
- 2.25 kg
- Heavy duty metal case
- Agricultural tractors and off road vehicles
Technical Drawing
Order Code
MO 382 - | X - Pedal Rod Type | X - Sensor Position | PXXX Sensor Program |
|---|---|---|---|
C - Type C | V - Vertical | P009 - Dual Analog P009 | |
H- Horizontal | * |
* Different programs can be produced on request.
Example: MO 382 – C – V – P009
